AT-220 Antenna Tripod – 50 lb Load, 24.4"–41.1" Height
- Heavy-duty non-reflective nylon construction designed for EMC and EMI test environments.
- Stepless center rod adjustment with secure locking mechanism for precise antenna height positioning.
- Supports antenna loads up to 50 lbs (22.6 kg) for stable measurement setups.
- Collapsible and lightweight design for easy lab storage and transport.
- Ideal for radiated emissions pre-compliance and compliance testing.
- Supports monopole, loop, and horn antennas during laboratory measurements.
- Enables repeatable antenna height positioning in semi-anechoic chambers and OATS sites.
- Provides stable support during vertical and horizontal polarization changes.
- Useful for immunity testing antenna placement and alignment.
- Suitable for controlled antenna positioning in diagnostic troubleshooting environments.
- 50 lb Load Capacity
- 24.4"–41.1" Height Range
- Non-Reflective Nylon
- Stepless Height Adjustment
- Collapsible Design
- 1/4-20 Mounting Bolt
- Indoor/Outdoor Rated
- 3-Year Warranty
AT-220 Specifications:
| Specification | Details |
|---|---|
| Height Range | 62.1 cm to 104.5 cm (24.4" to 41.1") |
| Maximum Load | 50 lbs (22.6 kg) |
| Tripod Weight | 19 lbs (8.6 kg) |
| Construction | Nylon |
The table below shows AT-220 for suitable antenna models.
| Model No. | Tripod Height Range | Construction | For Antenna Models |
|---|---|---|---|
| AT-220 | 62.1 cm to 104.5 cm (24.4" to 41.1") | Nylon | AH-220, AM-741R, AL-130R |
Note: For tripod height extensions or custom height requirements, please contact us.
| Title | Link |
|---|---|
| AT-220 Datasheet | View PDF |
