The Com-Power ACS-230 series of broadband RF Power amplifiers; diverse in application, yet specifically geared for use in IEC 61000-4-6 immunity testing using coupling decoupling networks (CDN).
ACS-230-25W
150 kHz to 230 MHz
25 watts into 2:1 VSWR
43 dB ±2 dB gain
IEC 61000-4-6 compliance testing capability
ACS-230-50W
150 kHz to 230 MHz
50 watts rated output into 2:1 VSWR
47 dB ± 2 dB gain
IEC 61000-4-6 compliance testing capabilit...
ACS-250-100W
150 kHz to 250 MHz
100 watts rated output into 2:1 VSWR
50 dB ± 2 dB gain
IEC 61000-4-6 compliance
AFM-1500
87.5 MHz to 108 MHz
1500 watts nominal output
65 dBc harmonics specification
MOSFET technology broadband amplifier
ARI-150K
30 Hz to 150 kHz
150 W (1–2 Ω), 100 W (4 Ω), 50 W (8 Ω)
≤ 8 % distortion, ±5° phase response (up to 75 kHz)
ARI-300K
DC to 300 kHz
Up to 150 watts output into 1 Ω/2 Ω loads
≤ 0.3 % distortion
Designed for MIL-STD-461 / ...
