Standard Gain Horn Antenna
- The AH-640 Standard Gain Horn Antenna is suitable for use as an EMI test antenna for qualificationlevel regulatory compliance measurements (FCC, CE, MIL-STD-461, RTCA DO-160, FDA, SAE, etc.).
- AH-640 is a broadband horn antenna that offers excellent performance over the frequency range of 26.5 to 40 GHz.
- Most EMI test standards require the use of horn antenna for testing above 1 GHz. This Horn antenna is an excellent choice for both EMC radiated immunity and emissions testing.
- Broadband - 26.5 GHz to 40 GHz
- High Gain - Lower Floor Noise for Emissions
- Individual Calibration
- Three Year Warranty
- Frequency Range: 26.5 GHz - 40 GHz
- Power: 5 Watts continuous
- VSWR (Typical): 2.0: 1
- Polarization: Linear
- Impedance: 50 Ω
- Connector: SMA (f)
- Weight: 1.5 lbs./ 0.68 kg
- Size: 8.7 x 5.7 x 9 inches / 22 x 14.5 x 22.8 cm
- Mounting: 1/4 inch x 20 threads
